Screw Conveyor
Screw Conveyor is generally compose of the conveyor body, the inlet and outlet, device there parts. according to the Angle of the helical blade. it will be divide into entity helical surface, belt type helical surface and blades of helical surface there forms. but the blade of helical surface application is relatively is small. Mainly used for transporting materials with high viscosity and compressibility. and in the process of transporting, have completed at the same time of material mixing Etc.
Main Feature
1. Large carrying capacity safe and reliable.
2. The shell is made of seamless steel piple, the end of the flange connected to each other, good rigidity, have long service life.
3. Good sealing, smooth operation, easy installation, dismantling and changing.
4. The discharge hole is equipped with cleaning device, low noise, few wearing part and no-blocking material.
Structure Chart
Application
It's can be widely used in the different industries, such as building materials, chemical industry, electric power, metallurgy, coal, food and other industries, appliable to horizontal or oblique conveying powder, granulated and small lump materials, sush as coal, ash, slag cement, food, etc.
Technical Parameter
LS | 100 | 160 | 200 | 250 | 315 | 400 | 500 | 630 | 800 | 1000 | 1250 |
GX | 200 | 250 | 300 | 400 | 500 | ||||||
Dimater (mm) | 100 | 160 | 200 | 250 | 315 | 400 | 500 | 630 | 800 | 1000 | 1250 |
Screw Pitch (mm) | 100 | 160 | 200 | 250 | 315 | 355 | 400 | 450 | 500 | 560 | 630 |
Speed (r/min) | 140 | 120 | 90 | 90 | 75 | 75 | 60 | 60 | 45 | 35 | 30 |
Capacity QΦ=0.33(m³/h） | 2.2 | 7.6 | 11 | 22 | 36.4 | 66.1 | 13.1 | 160 | 223 | 304 | 458 |
Power Pd 1=10m(kw) | 1.1 | 1.5 | 2.2 | 2.4 | 3.2 | 5.1 | 4.1 | 8.6 | 12 | 16 | 24.4 |
Power Pd 1=30m(kw) | 1.6 | 2.8 | 3.2 | 5.3 | 8.4 | 11 | 15.3 | 25.9 | 36 | 48 | 73.3 |
Speed (r/min) | 120 | 90 | 75 | 75 | 60 | 60 | 45 | 45 | 35 | 30 | 20 |
Capacity QΦ=0.33(m³） | 1.9 | 5.7 | 18 | 18 | 29.1 | 52.9 | 69.8 | 125 | 174 | 261 | 305 |
Power Pd 1=10m(kw) | 1.0 | 1.3 | 2.1 | 2.1 | 2.9 | 4.1 | 4.7 | 6.8 | 9.4 | 14.1 | 16.5 |
Power Pd 1=30m(kw) | 1.5 | 2.3 | 4.5 | 4.5 | 7 | 8.9 | 11.6 | 20.4 | 28.3 | 42.2 | 49.5 |
Speed (r/min) | 90 | 75 | 60 | 60 | 45 | 45 | 35 | 35 | 30 | 20 | 16 |
Capacity QΦ=0.33(m³/h） | 1.4 | 4.8 | 15 | 15 | 21.8 | 39.6 | 54.3 | 97 | 149 | 174 | 244 |
Power Pd 1=10m(kw) | 0.9 | 1.2 | 1.9 | 1.9 | 2.5 | 3.4 | 4.3 | 5.4 | 8.1 | 9.5 | 13.3 |
Power Pd 1=30m(kw) | 1.2 | 2.2 | 3.8 | 3.8 | 5.4 | 6.8 | 9.2 | 16 | 24.4 | 28.6 | 39.9 |
Speed (r/min) | 75 | 60 | 45 | 45 | 35 | 35 | 30 | 30 | 20 | 16 | 13 |
Capacity QΦ=0.33(m³/h） | 1.2 | 3.8 | 11 | 11 | 17 | 31.7 | 46.5 | 73.0 | 99.3 | 139 | 199 |
Power Pd 1=10m(kw) | 0.75 | 1.1 | 1.6 | 1.6 | 2.1 | 3.1 | 3.7 | 4.6 | 5.7 | 7.7 | 11 |
Power Pd 1=30m(kw) | 1.1 | 1.8 | 3.4 | 3.4 | 4.4 | 5.6 | 8 | 14 | 16.7 | 23.2 | 33 |
Real Case
Using Tips
Screw Conveyor is suitable for working enviroment temperature which is between 20℃to 50 ℃; Including the horizontal screw conveyor, temperature of material conveyed should be lower than 200℃; Conveying distance less than 40 meters, maximum not exceeding 70 meters; Vertical screw conveyor, it's temperature should not be more 80 ℃, the vertical hight is not more than 8 meters.
Selection Model: LS Type screw conveyor can according to different customers production situation and production purpose to customize. production material could be all carbon steel, stone stainless steel, or all stainless steel, With food hygiene requirements of enterprise recommend stainless steel material, no request can use carbon steel.
Pre-sale Service
1. Help high-end customer to choose a suitable machine and develop local market.
2. We can offer an accurate quotation according to customer's model or drawings.
3. The drawing can be send if needed, we can help you design the whole line based on your model.
4. OEM and label service will be always available.
After-sale Service
1. 24 hours service online and fast response within 12 hours.
2. Quality warranty is 12 months from the shipping date.
3. Provide assembly instruction, technical date and related soft copies or video to ensure customer could install and debug by themselves.
FAQ
Q1: What's material do you want by screw conveyor?
Cement, sand, limestone and grain etc.
Q2: What's capacity of screw conveyor do you want?
EM: 20t/h, 50t/h, 100t/h Etc.
Q3: What's color of screw conveyor do you need?
The machine color can be customized by you required.
Q4: It's better if you have layout drawing or sketch?
We can re-made new products as your sketch picture.
