Rotary Vibrating Screen

Rotary Vibrating Screen

Model : TZS400-1500
Material : stainless steel/contact material stainless steel/carbon steel
Vibration frequency : 1500rpm
Vibration amplitude : 1~4mm
Power : 0.18-3kw
Rotary Vibrating ScreenTZS series three-dimension rotary vibration sieve is a high-precision fine powder sieving machine. It has the characteristics of low noise, high efficiency, contributing to quic
Product Details



Rotary Vibrating Screen


TZS series three-dimension rotary vibration sieve is a high-precision fine powder sieving machine. It has the characteristics of low noise, high efficiency, contributing to quick change-over net (only 3-5 minutes). its fully enclosed structure is suitable for Sieving and filtering granular, powder, mucus and other materials, and no dust drift.

Rotary vibration seive provide solutions to different industry's demand for dependable material separation, grading, impurity. These ideal machines are available for processing Flour, Sugar, Spices Chemicals and other dry or liquid filtration.

Function Principle

It's vertical motor, which is installed eccentric hammers on the top and bottom, is regarded as a vibratory source. The eccentric harmmer change rotation into horizontal, vertical and inclined movement, and then pass the movement to the sieving surface. Adjusting the phase angle on the top and bottom can change trajectories of the materials on the sieve.

Feature & Benefits

1. High efficiency & High density.

2. Small size and can be nived easily.

3. Clean & replace net conveniently.

4. Easy to operate, impurities and coarse materials can be discharged automatically.

本.jpg 图片1.png

Drawing Picture


Application


Technical Parameter

Model

TZS-400

TZS-600

TZS-800

TZS-1000

TZS-1200

TZS-1500

TZS-1800

Effective sieving diameter

(mm)

340

540

730

900

1100

1400

1700

sieve mesh number

(mm)

2-500

Layer number of sieve

1--5

1--3

Motor power

0.18

0.25

0.55

0.75

1.1

2.2

4

Overall Dimension

A

330

530

680

800

985

1190

1540

B

305

430

580

700

855

1050

1440

C

240

240

240

240

400

400

400

D

400

600

800

970

1170

1470

1770

E

80

100

125

150

180

200

200

F

70

70

90

100

120

120

120

G

320

430

540

645

750

930

1025

I

390

420

435

445

555

556

680

H  1 layer

635

780

850

865

1035

1070

1225

H  2 layers

770

897

1000

1015

1205

1250

1395

H  3 layers

870

1013

1150

1165

1375

1425

1560

Real Case


FAQ

Q1: What's main purpose of purchasing our machine?

Like: sieving flour powder & konjac flour

Q2: What's raw material name? Bulk density (kg/m³and water content (%)?

EM: Grain,Liquid,sand.......

Q3: How much mesh size do you want ( mesh size of each layer)?

Single layer or Multi-lyayer is available. it's also can be customized by your requirements.

Q4: What's usually local power supply        Voltage&       Frequency in your city?

Various power voltage: 110V 200V 240V 380V 415V 450V 550V
Power Frequency: 50HZ 60HZ or Single phase electricity

Q5: What's material for machine do you need?

A Stainless steel 304
B Carbon steel Q235
C Touching parts SUS304

Q6: How do you ensure the quality of your products?

A: Generally, our equipments are the most durable type in the industry, this is also the feature of the label impression of  the most of our customers at home or abroad.

Q7: How do your after-sale service work if the product got damaged?

A: During the maintenance period , our general after-sale service is changing the damaged parts for the customer. Normally, we will provide on-site guidance.
