Flexible discs
Flexible discs, rubber flexible discs, flexible plates, and rubber flexible plates are sold directly nationwide. Flexible discs and couplings overcome the defect of easy damage to universal couplings, and rubber flexible discs are used in vibrating screens. It usually has circular, hexagonal, and octagonal rubber composite components with a thickness of 10-50mm. It is wrapped with vulcanized natural rubber on the outside and has several steel positioning sleeves inside. Many layers of high-strength silk thread are wrapped between the steel sleeves; Flexible discs are used in the transmission of vibration machinery due to their various characteristics such as smooth power transmission, high impact buffering performance, and large torque.
Commonly Used Size
Hole spacing * thickness * number of holes | |
170*12*6 | 120*25*6 |
168*31*6 | 240*30*6 |
240*50*8 | 160*50*6*φ25 |
220*30*6 | 160*50*6*φ21 |
250*30*8 | 160*33*6*φ21 |
200*12*6 | 200*30*6*φ21 |
240*31*8 | 180*50*6*φ21 |
