Reasons for slow feeding of vibrating hopper?

Date:2023-06-27 15:43:49
View: Point


Reasons for slow feeding of vibrating hopper

1. Insufficient inclination of the chute

Solution: Adjust the installation angle. Select the fixed positions at both ends of the feeding machine for raising/lowering according to the on-site conditions.

2. The angle between the eccentric blocks at both ends of the vibration motor is inconsistent

Solution: Adjust by checking whether the two vibration motors are consistent.

3. The vibration direction of the vibration motor is consistent

Solution: It is necessary to adjust the wiring of either vibration motor to ensure that both motors operate in reverse and that the vibration trajectory of the vibration feeder is straight.

4. Insufficient excitation force of vibration motor

Solution: The position of the eccentric block can be adjusted by adjusting it (the adjustment of the excitation force is achieved by adjusting the phase of the eccentric block. One of the two eccentric blocks is fixed and the other is movable, and the bolt of the movable eccentric block can be loosened. When the phases of the two eccentric blocks coincide, the excitation force is maximum and decreases in sequence; when adjusting, it should ensure that the phase of the eccentric blocks of the same group of motors is consistent).


The above is the reason for the slow feeding of the vibrating hopper. If you have any relevant screening questions or needs and would like to learn more about product information, please call+86-1232806514, and we will be happy to serve you.
